1.Detail Specification
|
Type |
S-R6A13 |
|
Thread |
M22x1.5 |
|
Reach |
30mm |
|
Hex |
22.2mm |
|
Seat Type |
Flat |
|
Gap |
0.3mm |
|
Electrode Type |
Prechamber |
|
Cable Length |
965mm |
|
Shield Length |
276mm |
|
Resistor or Non-Resistor |
Resistor |
|
Note |
Shielded replace 1228-2839 for MWM TCG 2032 |
|
Replacement |
DEUTZ: 1228-2839 /1228-4236 |
|
Application |
MWM: TCG 2032 V16, V20 / CAT CG260 |
2. Packing Information
>One in plastic box; 4 in cans; MWM is installed in plastic pipe.
>Pack as required.
