1.Detail Specification
|
Type |
S-R6A15 |
|
Thread |
M18x1.5 |
|
Reach |
26mm |
|
Hex |
22.2mm |
|
Seat Type |
Flat |
|
Gap |
0.3mm |
|
Electrode Type |
Prechamber |
|
Cable Length |
310mm |
|
Shield Length |
196mm |
|
Resistor or Non-Resistor |
Resistor |
|
Note |
Shielded replace 1231-9475 for MWM TCG 2016 |
|
Replacement |
CATERPILLAR: 1234-4096/1245-3562/1234-3055/1231-9475/1234-2668/1234-3755 2G: 3209000017 Storm: 0190880022 |
|
Application |
MWM: TCG2016 / CAT Cg132 GUASCOR: HGM 560 |
2. Packing Information
>One in plastic box; 4 in cans; MWM is installed in plastic pipe.
>Express, by air, by sea or according customers request.
>Customized
